Pine MDF Machinery

MDF is a kind of excellent substitute for natural wood panel with wide application. The panels are characterized with tight and smooth surface, uniform core layer and good wood working performance.

The line consists of material preparation section, fiber preparation section, glue mixing andapplying section, forming and hot-pressing section, cooling and trimming section, sanding section.

This section including forming, pre-pressing, mat conveying, mat cutting, hot-pressing, cooling and trimming, to produce quality board.

Dried fiber is transported at a certain speed to the upper part of forming machine (the spreader/former), then spread evenly onto annular screen-belt conveyer by spike-rolls. There is vacuum box under the screen-belt, air is sucked through the screen-belt and fiber is adhered on the screen-belt, thus forming a loose mat. Pressed by the pre-press, the loose mat is reduced into a relatively density mat, then cut into sized mat by mat-transversal-and-longitudinal saw. Transported by synchronous conveyer, acceleration belt conveyer, and fast-speed belt conveyer, the mat is carried to board loader. The cauless belt-trolley of the loader transports the mats into hot press, meanwhile, the pressed rough board is pushed out. When the cauless belt-trolley of the loader reaching its terminal point, the pressed rough board enters unloader completely, at the same time, mat reaches its position in hot-press. The mat stays on the press-platen of a hot press, then it is pressed into a certain thickness by the hot press. Meanwhile, the inner adhesive is hardened, thus a piece of fiberboard (rough board) with certain strength is produced. After pressing, the fiberboard is transported to the next section.

(1) Over 30 years manufacturing experience in wood-based panel making machinery.

(2) 20 years exporting experience to over 30 countries all over the world.

(3) Customized machines according to every customer's actual production demand with best production solutions.

(4) Free design the whole factory production plant with economy investment budget.

(5) Whole process control from placing order - production - containers loading - customs documents courier - containers unloading - machines installation & debugging.

(6) 2 Years quality guaranteen period & life-time free online after-sales service.

(7) Professional after-sales team over 10 years oveseas installation and debugging experience.

(8) Free training and guidance for workers on machines' operation and wood-based panel production technology.
