Product Description
Wood Working Machinery Panel Board Turnover Machine
Apply two layers rubber rollers conveyor pinch the board gently and stably when it pass through detector, cooperated with air cylinder and motor drive rotating that turn over the board up side down then continue to follow process.
Mainly use to complete line that coating double face of board or better pile up protect the finish side.
Application Field
Furniture, Cabinet, Door, Floor, Bathroom, Building wall, etc.
Application Material
Wood, Mdf, Ply, Glass, Metal, Ceramics, Fiber cement board, etc.
Product Parameters
| Wood Working Machinery Panel Board Turnover Machine | ||||
|
Model |
FM-PTM1300 |
|||
|
Overall dimensions L/W/H |
3100*1930*1700mm |
|||
|
Max working width |
1300mm |
|||
|
Min working length |
500mm~2800mm |
|||
|
Full power |
2.95kw 380V 50HZ 3P |
|||
|
Feeding speed |
3PCS/min |
|||
|
Estimated weight |
1250kg |
|||
|
Brand |
FOCUS MACH |
|||
|
Application field |
Door, furniture, decoration, building insulation, etc. |
|||
|
Application material |
Wood, pvc, glass, fiber cement board, calcium silicate board, marble, etc. |
|||
|
Certificate |
CE, ISO9001 |
|||
|
Warranty |
One year, lifetime service |
|||
