1, the roller adopts imported 20-40 degrees natural wear resistant rubber, sand belt speed frequency conversion adjustment, suitable for various paint characteristics, and can effectively eliminate the phenomenon of horizontal white edge.
2, the raw material conveying adopts the press shoe with the press roller structure, and the large-area deformation of the plate can be processed.
3, the body adopts steel plate bending and welding, large weight, stable operation.
4, the lifting of the table adopts four-column lifting mechanism, less error, high precision.
5, the polishing transmission structure can effectively remove the traces left by the sand, improve the surface effect after painting.
Products Description
| width of sanding panel | 40-1300mm |
| thickness sanded panel | 3-120mm |
| speed of abrasive belt on 1st unit | 18m/s |
| speed of abrasive belt on 2nd unit | 18m/s |
| speed of abrasive belt on 3rd unit | 14m/s |
| speed of conveyor belt | 6-30m/s |
| size of conveyor belt | 1300*2500mm |
| total motor power | 93.62kw |
| 1st unit motor | 37kw |
| 2nd unit motor | 30kw |
| 3rd unit motor | 22kw |
| conveyor belt motor | 4kw |
| lifting motor power | 0.25kw |
| brush motor power | 0.37kw |
| working pressure | 0.55mpa |
| weight | 4500kg |
| overall dimensions | 2600*2575*2130mm |
| volume of sucked air | 13000m3 |
| consumption of compressor air | 0.3m3 |
