Finger Joint Board Hot Press Machine

The Plywood Hot Press Machine is a crucial piece of equipment in the plywood production process, as it plays a pivotal role in ensuring the quality and efficiency of the final product. Its heavy, solid, and reliable structure provides stability and durability during operation, contributing to consistent and high-quality output.

Send Inquiry

Description

Expanded sentence: The Plywood Hot Press Machine is a crucial piece of equipment in the plywood production process, as it plays a pivotal role in ensuring the quality and efficiency of the final product. Its heavy, solid, and reliable structure provides stability and durability during operation, contributing to consistent and high-quality output. The double entrances and exits on the plates are meticulously designed to optimize efficiency by minimizing temperature differences across the surface area.

Moreover, the individual control valves for each platen not only ensure precise temperature control but also make future maintenance hassle-free. The flexibility offered by the input and output tubes, which can accommodate both steam and heat conduction oil interchangeably, adds versatility to its functionality. Additionally, with a larger diameter oil cylinder that is heavy-duty and a solid inside pillar compared to hollow alternatives, this machine exemplifies robust engineering.

The impressive closing time of 12-15 seconds sets it apart from other machines in its class that may take more than 20 seconds. Furthermore, utilizing PTFE for the infeed and outfeed pipes enhances their durability significantly when compared to those made using PVC materials. Lastly, featuring a plunger made from 15mm condensing cast iron with chromium plating process further underscores its commitment to reliability and longevity in demanding industrial settings.

Hot press Plate Size	2700137052mm, 16 pieces
Opening Size	70mm
Hydraulic Pistons Diameter	2 units, diameter 320mm, stroke 1050mm
Nominal Pressure	400 Tons
No-Load Closing Time	About 30 seconds
Control Mode	Manual or automatic
Hydraulic System Limit Pressure	25Mpa
Low Pressure Pump	250ml/ rev, 11KW
High Pressure Pump	10ml/rev, 5.5KW
Heating Medium	Steam or heat transfer oils
Machine Size	356013704590mm
Gross Weight	38500KG
