Wood Industry Veneer Peeling Knife

This knife is highly versatile and finds applications in multiple scenarios. In plywood production, it is used to peel thin layers of wood veneer from logs, ensuring smooth and uniform sheets that form the core of plywood. In the furniture manufacturing industry, it plays a crucial role in creating high - quality veneers for adding decorative finishes to furniture pieces, enhancing their aesthetic appeal. For the production of decorative materials such as wall panels and cabinet fronts, the knife enables the precise peeling of veneers that can be used to create attractive surface patterns.

Send Inquiry

Description

Wood Industry Veneer Peeling Knife

The Wood Industry Veneer Peeling Knife is designed with specific dimensions, featuring a length of 400 mm, width of 50 mm, and thickness of 6 mm. Its blade angles, including a 10° rake angle, 5° clearance angle, and 85° wedge angle, are optimized for efficient cutting. The tool body is made of cemented carbide, and the blade is coated with Titanium Nitride (TiN) for enhanced hardness and wear resistance.It operates at a recommended linear speed of 30 - 50 m/min, with a feed rate of 0.1 - 0.3 mm per revolution and a maximum cutting depth of 3 mm. The knife offers high precision, with an edge straightness of ±5 μm and tool parallelism of ±10 μm. Under normal conditions, it can process 50 - 100 m³ of wood before requiring sharpening. It is suitable for various wood species such as oak, pine, birch, poplar, and walnut. The mounting method involves bolting and connection to the equipment through a special tool holder equipped with precise positioning grooves to ensure accurate installation.

Product Parameters

Parameter	Details
Tool Dimensions	Length: 400 mmWidth: 50 mmThickness: 6 mm
Blade Angles	Rake Angle: 10°Clearance Angle: 5°Wedge Angle: 85°
Material	Tool Body: Cemented CarbideBlade Coating: Titanium Nitride (TiN)
Cutting Speed	Recommended Linear Speed: 30 - 50 m/min
Feed Rate	Feed per Revolution: 0.1 - 0.3 mm/rev
Cutting Depth	Maximum Cutting Depth: 3 mm
Tool Precision	Edge Straightness: ±5 μmTool Parallelism: ±10 μm
Durability	Under normal operating conditions, it needs to be sharpened after processing 50 - 100 m³ of wood
Applicable Wood Species	Oak, Pine, Birch, Poplar, Walnut
Mounting Method	Fastened with bolts, connected to the equipment through a special tool holder. There are precise positioning grooves on the tool holder to ensure installation accuracy
