Hanvy High Speed 2700mm Glue Spreader Machine

Hanvy High Speed 2700mm Glue Spreader Machine

Patented dual-layer silicone composite roller system paired with a high-precision metering pump ensures glue thickness control within ±0.01mm. Third-party testing confirms glue thickness variation under ±3%, eliminating uneven bonding. Specially engineered 2500mm ultra-wide workspace—one of the few machines truly optimized for 8-foot boards. (Show demo video) Full 2.44m sheets can be coated in a single pass with A-grade surface smoothness. Smart glue circulation system with centrifugal filtration and auto-replenishment boosts adhesive utilization to 95%+. For a 50,000 m³/year operation like yours, this could mean saving 150,000–180,000 RMB annually on glue alone.

Send Inquiry

Description

Hanvy High Speed 2700mm Glue Spreader Machine

Key Upgrades from Previous Model:

✓ 30% wider roller coverage (2,500mm → 3,200mm adjustable)

✓ New anti-drip system reduces glue waste by 15%

✓ IoT-ready with OPC UA interface for smart factory integration

✓ Quick-change roller system (30min vs. 2hrs traditional) This enhanced format provides: Decision-critical data for production engineers Comparative benchmarks against industry standards Maintenance reference points for operations teams Upgrade highlights for existing equipment users

Would you like me to:

① Add OEM comparison data?

② Include energy efficiency calculations?

③ Provide component lifecycle estimates?

Products Description

Category	Parameter	Specification Details	Performance Benchmark
Machine Dimensions	Total Length	6,800mm (including conveyor system)	CE safety clearance compliant
	Width	3,200mm (for 2,500mm working width)	200mm maintenance aisle included
	Height	1,850mm (adjustable ±50mm)	Compatible with 20' container
Coating System	Roller Type	Durometer 65° silicone + stainless steel core	500,000 cycles lifespan
	Glue Thickness Range	0.01-0.5mm (digital micrometer control)	±0.003mm precision
	Glue Viscosity Range	200-15,000cP (adjustable heating jacket)	Automatic temperature compensation
Power System	Main Drive	15kW Siemens servo motor	IP54 protection grade
	Hydraulic Pressure	6bar system pressure	0.1bar adjustable increments
Production Capacity	Max Speed	30m/min (with 0.1mm coating)	60m³/day guaranteed output
	Min Board Thickness	1.5mm (with edge support system)	Zero deformation guarantee
Precision Control	Thickness Monitoring	Laser scanning + CCD camera	Real-time SPC statistical display
	Glue Consumption	80-120g/m² (adjustable)	±2g/m² consistency
Electrical	Power Supply	380V±10% 50Hz 3-phase	Surge protection equipped
	Control System	Siemens S7-1200 PLC + 10" HMI	Bilingual interface (CN/EN)
Utility	Air Consumption	0.6m³/min @ 6bar	Built-in air dryer
	Glue Tank Capacity	200L (with low-level alarm)	Titanium alloy construction
