Particle board production line For Wood machine hot press for plywood production line /hydraulic hot press machine for plywood
Short cycle melamine laminating hot press machine is widely used in wood processing, building materials and decoration...etc.. It is suitable for the veneered processing of particle board, OSB, MDF, HDF and melamine impregnated paper and high density laminated flooring ACP wear-resisting paper. Variety specifications include 4*8', 4*9', 5*8', 5*9', 6*8', 6*9', 7*8', 7*9', 6*12...etc.
Variety models include 1200T, 1400T, 1600T, 1800T, 2000T, 2400T, 2800T, 3200T series lamination hot pressing machine.
1. Short cycle hot press for door skin
2. Furniture board laminating hot press
3. Melamine MDF/particle furniture board
4. Veneer MDF/particle furniture board
5.Hydraulic part adopts imported hydraulic control system
6.PLC control adopts touch screen operation, make the machine high degree of automatic,high reliability,easy adjustment.
Products Description
|
Type |
Size(ft) |
Nominal Pressure(KN) |
The Finished Board Size(mm) |
Working Pressure(kg/cm2) |
Main oil cylinder(Diameter×Quantity) |
|
TP-900T |
4×8 |
9000 |
1220×2440 |
≤30 |
Φ280×6 |
|
TP-1200T |
4×8 |
12000 |
1220×2440 |
≤40 |
Φ320×6 |
|
TP-1400T |
4×8 |
14000 |
1220×2440 |
≤47 |
Φ340×6 |
|
5×8 |
1550×2440 |
≤37 |
Φ340×6 |
||
|
6×8 |
1830×2440 |
≤31 |
Φ340×6 |
||
|
TP-1600T |
4×8 |
16000 |
1200×2440 |
≤53 |
Φ380×6 |
|
4×9 |
1200×2750 |
≤47 |
Φ380×6 |
||
|
5×8 |
1500×2440 |
≤42 |
Φ380×6 |
||
|
7×9 |
2100×2750 |
≤27 |
Φ380×6 |
Detailed Photos
EXHIBITION
PACKING AND SHIPPING
COMPANY PROFILE
