Products Description
Maximize efficiency with our Heavy-Duty Wide Belt Sanding Machine, perfect for sanding wood, plywood, and MDF. Its reinforced frame ensures durability, while the oversized sanding roller provides even abrasion. The 100mm marble conveying table offers unmatched stability, reducing material vibration.
Precision is guaranteed with the Autonics photoelectric sensor (South Korea), preventing belt misalignment. Japanese Riken sandpaper ensures a flawless finish, and the variable-speed frequency inverter allows customized sanding speeds.
The large worktable supports big panels, improving workflow efficiency. Premium imported rollers and high-end electrical systems enhance longevity and performance. Additional highlights include automatic sandpaper retention, oil lubrication components, and Taiwan-made screws for precision assembly.
Built for demanding industrial applications, this belt sander delivers unmatched accuracy and reliability, making it an essential tool for woodworking shops and manufacturers.
Product Parameters
|
Sanding Width
|
1300mm
|
|
Sanding Thickness
|
3-110mm
|
|
Min. Board Length
|
550mm
|
|
First Sanding Roller Motor Power
|
37kw
|
|
First Sanding Roller Diameter
|
240mm(steel)
|
|
Second Sanding Roller Motor Power
|
22kw
|
|
Second Sanding Roller Diameter
|
210mm(rubber)
|
|
Feeding Motor Power
|
4kw
|
|
Lifting Motor Power
|
0.55kw
|
|
Air Pressure
|
0.6Mpa
|
|
Sanding Belt Size
|
1320*2200mm
|
|
Feeding Speed
|
30-60m/min
|
|
Weight
|
3300kgs
|
|
Net weight
|
2000kg
|
