3 Deck 20M Veneer Roller Dryer

Veneer roller dryer can consistently produce high-quality veneer that has a uniform dry moisture content, an aesthetic appearance, and is supple enough to minimize damage during the stacking process. Moreover, the veneer is dried in the most cost-effective and environmentally friendly manner. This implies using the least amount of thermal energy and producing a minimum of volume dryer exhaust.

Send Inquiry

Description

Products Description

3 Deck 20M Veneer Roller Dryer

The FM/GTH30-20 3-deck veneer drying machine is a high-efficiency solution designed for modern veneer production. With a working width of 3000mm and a heating area length of 18m, it efficiently dries veneer from an initial moisture content of 50-80% down to ~10%. The machine accommodates veneer thicknesses ranging from 0.6-8mm and operates at adjustable temperatures of 140-200℃ (±5℃ accuracy), ensuring consistent moisture content through automatic temperature and speed control systems. Powered by a 4-ton biomass burner that utilizes waste wood, it significantly reduces fuel costs while maintaining eco-friendly operations.

The machine is equipped with hot air blowers (5.5KW x 9), traction motors (4KW x 3), and cold air blowers (5.5KW x 2), with a total power consumption of 135.9KW and an actual hourly usage of 80-90KW. Optional automatic feeding (24.2KW) and collecting systems (6.2KW) further enhance productivity.
