Wood veneer dryers play a crucial role in the wood processing industry by effectively reducing the moisture content of peeled veneers. This process is essential to ensure that the veneers meet the required standards for use in various wooden products, including plywood, LVL (Laminated Veneer Lumber), wooden chairs, and other items. The necessity of drying veneers stems from the inherent moisture retained within wood after it has been peeled to produce veneers. Different wood species possess varying levels of natural moisture content, and additional factors such as pre-peeling boiling treatments can result in humidity levels ranging from 40% to 70%. Such high humidity renders the wood unsuitable for subsequent production steps such as glue coating, emphasizing the critical role of utilizing a specialized veneer dryer. In response to increasing market demand and evolving technological advancements, mesh veneer dryers have gained significant popularity within the industry. The term "mesh dryer" refers to its conveyance method using mesh wire, which allows for efficient and uniform drying of large quantities of veneers. These advanced dryers are designed with diverse specifications tailored to specific drying capacities and requirements, encompassing variations in layers, drying widths, heating sections, and overall operational efficiency. Overall, through meticulous control over moisture content achieved by employing advanced wood veneer dryers like mesh dryers with precise specifications tailored to industrial needs ensures that high-quality dried veneers are readily available for utilization across a wide spectrum of wooden product applications.
|
Working width |
2800 mm |
|
|
Working decks |
3 decks |
|
|
Length of heating section |
13*2000 = 26000mm |
|
|
Length of cooling section |
2*2000 = 4000mm |
|
|
Total power |
181.7kw |
|
|
Transport motor |
7.5kw*3 = 22.5kw |
|
|
Heating motor |
11kw*13 = 143kw |
|
|
Cooling motor |
4kw*2 + 3kw*2 = 14kw |
|
|
Out put stacker |
2.2kw*1 = 2.2kw |
|
|
Veneer transportation speed |
1.5~15m/min |
|
|
Heating medium |
Saturated steam |
Thermal oil |
|
Saturated steam pressure |
0.6~1.0Mpa |
|
|
Drying temperature |
150~170ºC |
170~190 ºC |
|
Steam consumption |
4300kg/h |
|
|
Oil boiler capacity |
|
2,600,000 Kcal |
|
Veneer density |
~590kg/m³ |
|
|
Available veneer thickness |
1.5~3.2mm |
|
|
Veneer initial moisture content |
70~80% |
|
|
Veneer final moisture content |
10~12% |
|
|
Load ratio |
85% |
|
|
Drying capacity |
~4.3m³/h |
|
|
Roller spacing |
333mm |
|
|
Overall dimension (L*W*H) |
46970*5150*4150mm |
|
|
Front veneer conveyor |
6525mm |
|
|
Back veneer conveyor |
7365mm |
|
|
Hydraulic lift BSJ48-3T |
3 pieces (for two in lets and one exit) |
|
|
Lift table specifications |
Stroke: 450~1650mm |
|
|
Total weight |
98800KGS |
|
|
Containers |
3*40HQ |
|
